Split Container¶

The split container is a container with a movable split and the option for 2 or 3 elements.

Usage¶

import toga

split = toga.SplitContainer()
left_container = toga.Box()
right_container = toga.ScrollContainer()

split.content = [left_container, right_container]

Setting split direction¶

Split direction is set on instantiation using the direction keyword argument. Direction is vertical by default.

import toga

split = toga.SplitContainer()
left_container = toga.Box()
right_container = toga.ScrollContainer(direction=toga.ScrollContainer.HORIZONTAL)

split.content = [left_container, right_container]

Supported Platforms¶

orphan:

Component	iOS	win32	web	django	cocoa	gtk	android
SplitContainer

Reference¶

class toga.interface.widgets.splitcontainer.SplitContainer(id=None, style=None, direction=True, content=None)¶

Split container widget

Instantiate a new instance of the split container widget

Parameters:	id (`str`) – An identifier for this widget. style (`colosseum.CSSNode`) – an optional style object. If no style is provided then a new one will be created for the widget. direction (`bool`) – The direction for the container split, either SplitContainer.HORIZONTAL or SplitContainer.VERTICAL content (`list` of `toga.Widget`) – The list of components to be split

HORIZONTAL = False¶

VERTICAL = True¶

add(child)¶

Add a widget as a child of this one.

Raises an ValueError if this widget is a leaf, and cannot have children.

Parameters:	child (`toga.Widget`) – The child to add to the widget

app¶

The App to which this widget belongs.

Return type:	`toga.App`

children¶

The children of this node.

This always returns a list, even if the node is a leaf and cannot have children.

Return type:	`list`
Returns:	A list of the children for this widget

content¶

The content of the split container

Return type:	`list` of `toga.Widget`

direction¶

The direction of the split

Return type:	`bool`

hide()¶: Hide the widget from the super view.

id¶

The node identifier. This id can be used to target CSS directives

Return type:	`str`

on_resize()¶

parent¶

The parent of this node.

Return type:	`toga.Widget`

set_font(font)¶

Set a font on this widget.

Parameters:	font (`toga.Font`) – The new font

show()¶: Show the widget on the super view.

style¶

The style object for this widget.

Returns:	The style for this widget
Return type:	`colosseum.CSSNode`

window¶

The Window to which this widget belongs.

Return type:	`toga.Window`
